| Catalogue number |
CA155WMP-GB
|
| GTIN |
5030216396746
|
| Production model |
CA155WMP-GB
|
| With wired control unit | |
| Suitable for wireless remote control | |
| Supporting protocol for Modbus | |
| With internal carbon dioxide (CO2) sensor | |
| Residential connection, left side | |
| Suitable for floor mounting | |
| Suitable for (extra) carbon dioxide (CO2) sensor | |
| Voltage |
230
V
|
| With internal humidity (RH) sensor | |
| Suitable for ceiling mounting | |
| With zone controller | |
| Left/right orientation reversible | |
| Efficiency supply filter according to ISO 16890-1:2016 |
0.45
%
|
| Depth |
298
mm
|
| Roof connection, top | |
| Supply filter according to ISO 16890-1:2016 |
ISO Coarse
|
| Max. air volume at 150 Pa |
230
m³/h
|
| Height |
644
mm
|
| Residential connection, top | |
| Exhaust filter according to ISO 16890-1:2016 |
ISO Coarse
|
| Efficiency exhaust filter according to ISO 16890-1:2016 |
0.45
%
|
| Weight |
18
kg
|
| With thermal overload protection | |
| Suitable for (extra) humidity (RH) sensor | |
| Type of motor |
Electronically commutated (EC)
|
| Suitable for zone controller | |
| Electrical connection |
Cable
|
| Suitable for wired control unit | |
| Suitable for wall mounting | |
| Max. air volume at 50 Pa |
234
m³/h
|
| Frequency |
50
Hz
|
| Width |
546
mm
|
| Max. air volume at 100 Pa |
250
m³/h
|
| Suitable for central heating boiler connection | |
| With constant pressure control | |
| Roof connection, side | |
| With constant volume flow control | |
| Max. air volume at 200 Pa |
200
m³/h
|
| Type of frost protection |
Other
|
| Energy efficiency class |
A+
|
| Connections residential side |
Duct end
|
| Residential connection, underside | |
| Connections outdoor air side |
Duct end
|
| Residential connection, right side | |
| With bypass | |
| With digital display | |
| Material housing |
Plastic
|
| Thermal efficiency according to EPN standard |
0.93
%
|
| With heating element | |
| Number of phases |
1
|
