Decorative Radiators

Zehnder
Quaro Spa

Electric operation

    Distinct shapes; strong, subtle design. The square design of Zehnder Quaro does not intrude but rather complements its surroundings. It is a perfect fit for any modern bathroom. Generous spaces between the tubes are perfect for hanging towels. Timeless design through a geometric shape, which also makes for an impressive room divider. Available in almost any colour and finish from the Zehnder colour chart.

    Decorative Radiators

    Zehnder Quaro Spa - Electric operation

    We also offer the following technologies

    Hydronic operation

    Benefits

    • Stylish design through straight-edged clarity
    • Generous spaces between the tubes are perfect for hanging towels
    • Ample spaces between tubes make cleaning easy
    • Discreetly concealed brackets in square design match the radiator
    • Special solutions support a wide range of applications, such as room dividers
    • Generous spaces between the tubes are perfect for hanging towels
    • Brushed stainless steel version ensures resistance to corrosion

    Electric operation

    • User-friendly control device allows simple operation
    • Dry-running protection prevents temperature warning
    • Electric operation provides warm towels and comfortable rooms all year round
    • Low energy consumption of only 0.5 W or less in stand-by mode for increased energy efficiency
    • Flexible control options: control device for wall mounting or base mount
    • Demand control using daily and weekly programme
    • Comes with flying lead to connect in accordance with local electrical regulations for easy and quick installation
    • Energy-efficient and comfortable heating with innovative “open window detection”
    • Customisable daily and weekly programmes for convenient, on-demand operation
    • Maximum surface temperature of 65°C ensures increased safety (chrome-plated version)
    • Timer function for on-demand operation
    • Factory-assembled, elegantly integrated electric heating element reduces cost of installation
    • High energy efficiency due to compliance with the European Ecodesign Directive reduces energy costs
    • Increased safety with keylock

    Colour System

    Zehnder Quaro Spa - Electric operation
    Traffic White (9016* / RAL 9016)
    * These colours / surfaces are glossy, all others matt.
    Despite extreme care in the painting process of our radiators, slight colour deviations are possible, depending on the production series and compared to other colour carriers (ceramic, paper, metal, ...) as well as screen display.
    RAL and NCS are manufacturer's designations.

    Technical data

    Electric-only operation

    Painted version
    Model H HT L Power electric heating element
    mm mm mm Watts
    QSE-075-045/GF 803 833 450 300
    QSE-120-045/GF 1251 1281 450 500
    QSE-120-055/GF 1251 1281 550 500
    QSE-150-045/GF 1507 1537 450 500
    QSE-150-055/GF 1507 1537 550 600
    QSE-180-055/GF 1827 1857 550 750
    H = height, L = length
    HT = Total height incl. electric heating element
    Chrome-plated version
    Model H HT L Power electric heating element
    mm mm mm Watts
    QSEC-120-045/GF 1251 1281 450 300
    QSEC-120-055/GF 1251 1281 550 300
    QSEC-150-045/GF 1507 1537 450 300
    QSEC-150-055/GF 1507 1537 550 300
    QSEC-180-055/GF 1827 1857 550 500
    H = height, L = length
    HT = Total height incl. electric heating element
